Stone Marble Bridge Cutting Machine Faults and Solutions

A bridge saw or also called a sawing machine or cutting centre for natural stone or ceramics is a very large saw that runs on a beam or bridge. This guarantees professional quality cuts. Bridge saws are used to cut stone, granite, marble, ceramics and all other types of slabs. This cutting is called secondary cutting and takes place after the primary sawing carried out by diamond wire machines or diamond blades.

Bridge Cutting Machine Faults and Solutions

Marble Bridge Cutting Machine Cutting accuracy problem

1. Check whether the blade is worn or replace it with a new one;
2. Adjust the cutting speed to avoid uneven cutting surfaces caused by excessive speed;
3. Check the machine’s positioning system to ensure accurate positioning.

bridge saw cutting machine does not start

1. Check whether the power plug is plugged in properly;
2. Check whether there is any fault in the internal circuit of the machine.

Marble Bridge Cutting Machine Slow cutting speed

1、Replace with new blades to improve cutting efficiency;

2. Check whether the equipment transmission system needs lubrication or replacement.

Stone Bridge Cutting Machine Loud noise

1. Check whether the bearings are worn or damaged, and replace the bearings if necessary;

Bridge Cutting Machine Oil leakage

1. Check whether the sealing ring is aged or loose, and replace the sealing ring if necessary;
2. Regularly check the connection of each component of the machine to ensure there is no oil leakage.

Stone Bridge Cutter High blade temperature

1. Check whether the cooling system is working properly;
2. Replace the blade with a new one to avoid blade deformation caused by excessive temperature.

bridge saw cutting machine Unable to automatically locate

1. Check whether all components of the positioning system are working properly
2. Manually adjust the positioning position to ensure accurate positioning.

Bridge Cutting Machine The software cannot be opened

1. Check whether the document content of the file is intact and whether there are garbled characters, and back up the file again.

Bridge Cutting Machine Z-axis drops when turning on the machine

1. Check the air pressure of the nitrogen balance bar
2. Check the brake

bridge saw cutting machine Oil leakage from machine guide rails

1. Check whether the oil pot automatically absorbs oil
