Disc Automatic Tool Changer CNC Machine 2060

This Automatic Cabinet Making CNC Machine is a high-speed, automatic load/unload, heavy-duty CNC routing system for nested based feed through machining. This CNC machine is used majorly in the production of cabinets, closets, and custom furniture.

The machining center is equipped with saw blade spindle, linear tool changer, and automatic loading and unloading platform. It can ensure high productivity, high processing precision and low labor cost. Moreover, it adopts Taiwan helical rack and Taiwan TBI ball screw, which improve the processing precision and prolong the service life of the machine. It can be used in the production and processing of various wooden doors, plastic doors and cabinet doors.

Nesting CNC Machine 2060 Video

Disc magazine, 10 tool changers

Automatic tool setting instrument

Automatic feeding

Automatic unloading

Automatic loading and unloading platform

Highly automated discharge solution with automatic loading and unloading system. The entire work cycle of loading, nesting, drilling, and unloading is performed automatically, thereby achieving the highest productivity and zero downtime,it can effectively improve the production efficiency of cabinets and panel furniture.

* The cutting method can be flexibly matched according to the site and output.

Nesting CNC Machine 2060 Parameter

Technical Data

Model	iGC-DT-2060
Structure	Seamless steel welded , quenching treatment and milling
Table	Vacuum table structure
XYZ working size	20006000200mm
XYZ transmission	XY axis is Taiwan helical rack and gear,Z axis is Taiwan Ball Screw
XYZ guide rail	Taiwan Hiwin Line 30mm Square guide way
Spindle	9kw ATC Italy HSD brand spindle
Spindle collet	ER32
Inverter	Well known Delta brand
Motor	Japan YASKAWA Servo 850W
Driver	Japan YASKAWA Servo
Reducer	Japan Shimpo
Controller system	Taiwan Syntec 6MB Control system
Voltage	380v, 50/60HZ
Tools magazine	Disk 12 tools
Dust collector	5.5KW double bags dust collector
Lubrication	Automatic lubrication
Air cylinder position	3+4
Vacuum pump	3 sets
Tool sensor	Automatic

We offer customized services according to your requests such as the working area and specifications.

Automatic Cabinet CNC Machine Applications:

The most advanced, multi-function ATC Nesting CNC machine with drilling bank, perfect for professional scaled furniture manufacturers, designed by iGOLDENCNC for changing tools automatically while working, combined with a competitive set of configurations.

Hot applications include:

>Production and processing of various types of furniture: cabinets, wardrobes, office furniture, computer tables, children’s furniture, panel furniture, cutting and cutting, slotting and perforating, decoration hollow frames, soft bag background wall production, etc.;

>Wooden door and furniture decoration industry: solid wood and composite door, cabinet door, large-area plate carving, solid wood, panel furniture carving, solid wood art mural carving, etc .;

>Wood products processing: clocks, electrical countertops, sporting goods and equipment;

>Musical instrument industry: three-dimensional curved surface and shape cutting of sculptable musical instruments;

>Crafts industry: photo frames, jewellery boxes.
